| No. | Item | Specifications | Post Environmental Tolerance |
|---|---|---|---|
| 1 | Range of Receiving Frequency(MHz) | 1575.42±3 | ±2.5 |
| 2 | Center Frequency(MHz) (with 30mm Square GND) | 1575.42 | ±3.0 |
| 3 | Band Width(MHz) (Return Loss ≤-10dB) | ≥10 | - |
| 4 | V.S.W.R (in Center Frequency) | ≤1.5 | - |
| 5 | Gain (Zenith)(dBi typ) (with 70mm Square GND) | 4.5 | ±0.5 |
| 6 | Axial Ratio (with 70mm Square GND) | 3.0dB | ±0.2 |
| 7 | Polarization | Right-Handed Circular | - |
| 8 | Impedance(Ω) | 50 | - |
